How effective is SOL 116 at controlling solar heat?

SOL 116 rejects 86% of total solar energy. It has a g-value of 0.14, 50% solar reflectance, 14% solar transmission, 36% solar absorption and 20% visible light transmission.

Is SOL 116 installed inside or outside?

It is installed exclusively on the exterior face of the glazing. This is particularly suitable for highly exposed glass where internal installation is not appropriate.

Which types of glazing are compatible with SOL 116?

The compatibility matrix allows exterior installation on single glazing, small and large double glazing, laminated glass and toughened glass. Carry out a preliminary test on acrylic or polycarbonate to rule out bubbling.

What warranty does SOL 116 have?

The warranty is 5 years for vertical exterior installation in Central Europe, provided that the preparation, installation and maintenance instructions are followed.

How should SOL 116 be cleaned?

Wait 30 days after installation before the first clean. Then use a standard non-abrasive, ammonia-free solution and cleaning tools that will not scratch the film.

NOS GAMMES>BUILDING RANGE>SOLAR FILMS>EXTERIOR SOLAR FILMS>SOL 116 - Reflective Silver Exterior Solar Film

Building Range

Sol 116

Name: SOL 116 - Reflective Silver Exterior Solar Film
Brand: Reflectiv
SKU: Sol116
Price: 72 EUR
Availability: OutOfStock

86% total solar energy rejected

SOL 116 is a reflective silver solar control film designed for exterior installation. It rejects 86% of total solar energy, with a solar factor g of 0.14 and 99% UV blocking, improving comfort behind heavily exposed glazing.

Exterior Solar Films

72,00 €HT

soit 86,40 € TTC

Laize (hauteur)

Longueur (au rouleau)

Compatibilité vitrage

Simple

Trempé

Double Vitrage <1,20m

Double Vitrage >1,20m

Feuilleté

Position de pose

Intérieure

Extérieure

Méthode d'application

La surface à coller doit être exempte de poussière, de graisse ou de tout autre contaminant. Certains matériaux comme le polycarbonate peuvent générer des problèmes de bullage. Un test de compatibilité est donc recommandé.

Description

SOL 116, exterior solar protection for heavily exposed glazing

SOL 116 is installed on the outside face of the glass, where it acts before solar radiation enters the building. It reduces heat gain and glare in offices, shops, reception areas and other commercial buildings with strong sun exposure.

The performance data shown on the product page is clear: 86% total solar energy rejected, a solar factor g of 0.14, 14% solar transmission, 50% solar reflection and 36% solar absorption. Visible light transmission is 20%, giving the glazing a pronounced reflective silver appearance. The film also blocks 99% of UV rays to help slow fading of interior furnishings.

Installation is exclusively exterior, using soapy water, on the glazing types marked as compatible in the product table. Its scratch resistant surface helps with maintenance and the exterior warranty is 5 years. SOL 116 is well suited to energy renovation projects requiring strong solar protection without replacing the existing glazing.

Durabilité

Garantie fabricant : 5 ans extérieure. La tenue réelle dépend de l’exposition, de la qualité du vitrage, du respect des conditions de pose et de l’entretien.

Entretien

30 days after installation.

Stockage

2 years from delivery. Store away from excessive humidity and sunlight, at a temperature below 38°C.

Performances

EN 410

Application faceExterior

SupportPET

Support Thickness67

ProtectorSilicone PET

Thickness Protector20

AdhesiveAcrylic polymer

ColorReflective silver

TOTAL SOLAR ENERGY RELEASED86%

SOLAR ENERGY REFLECTION50%

SOLAR ENERGY TRANSMISSION14%

SOLAR ENERGY ABSORPTION36%

SOLAR FACTOR G14%

UV BLOCKAGE99%

VLT20%

Guarantee5 ans extérieure

ApplicationSoapy water
